Home » Applications » Research Vessels » ROV Handling Winch X-Series

Features:

  • Planetary gearbox with variable displacement motor (2 speed ranges)
  • 3 braking systems: hydraulic, failsafe disk (gearbox), failsafe band (drum)
  • Winch designed and tested to DNV “Rules for Certification of Lifting Appliances”, type approval certificate S-3510
  • Built under DNV survey using –20oC, low temperature steel
  • Hollow stub shaft to accommodate Focal model 176 slip ring
  • Surround frame with corner lifting lugs designed to DNV 2.7-1
  • 150 hp power unit with raised operator’s plarform
  • Diamond screw levelwind, adjustable from 0-90o cable exit angles

    Options:

    • Payout and line speed display
    • Lebus grooved shell
    • DNV approved lifting sling

    Specifications:

    Please fill out the form to download the PDF.
